Cardiac catheterization and coronary angiography Angiography In angiography, x-rays are used to produce detailed images of blood vessels. It is sometimes called conventional angiography to distinguish it from computed tomography (CT) angiography and magnetic... read more are minimally invasive methods of studying the heart and the blood vessels that supply the heart (coronary arteries) without doing surgery. These tests are usually done when noninvasive tests Introduction to Diagnosis of Heart and Blood Vessel Disorders Sometimes, medical history and physical examination alone suggest to a doctor that the person has a heart or blood vessel disorder. However, special diagnostic procedures are often needed to... read more do not give sufficient information, when noninvasive tests suggest that there is a heart or blood vessel problem, or when a person has symptoms that make a heart or coronary artery problem very likely. One advantage to these tests is that during the test, doctors can also treat various diseases, including coronary artery disease Overview of Coronary Artery Disease (CAD) Coronary artery disease is a condition in which the blood supply to the heart muscle is partially or completely blocked. The heart muscle needs a constant supply of oxygen-rich blood. The coronary... read more .
More than a million cardiac catheterizations and angiographic procedures are done every year in the United States. They are relatively safe, and complications are rare. With cardiac catheterization and angiography, the chance of a serious complication—such as stroke Overview of Stroke A stroke occurs when an artery to the brain becomes blocked or ruptures, resulting in death of an area of brain tissue due to loss of its blood supply (cerebral infarction) and symptoms that... read more , heart attack Acute Coronary Syndromes (Heart Attack; Myocardial Infarction; Unstable Angina) Acute coronary syndromes result from a sudden blockage in a coronary artery. This blockage causes unstable angina or a heart attack (myocardial infarction), depending on the location and amount... read more , or death—is 1 in 1,000. Fewer than 1 in 10,000 people undergoing these procedures die, and most of those who die already have a severe heart disorder or other disorder. The risk of complications and death is increased for older people.
Cardiac catheterization is used extensively for the diagnosis and treatment of various heart disorders. Cardiac catheterization can be used to measure how much blood the heart pumps out per minute (cardiac output), to detect birth defects of the heart, and to detect and biopsy tumors affecting the heart Overview of Heart Tumors A tumor is any type of abnormal growth, whether cancerous (malignant) or noncancerous (benign). Tumors in the heart may be Primary (noncancerous or cancerous) Metastatic (always cancerous) Primary... read more (for example, a myxoma).
This procedure is the only way to directly measure the pressure of blood in each chamber of the heart and in the major blood vessels going from the heart to the lungs.
In cardiac catheterization, a thin catheter (a small, flexible, hollow plastic tube) is inserted into an artery or vein in the neck, arm, or groin/upper thigh through a puncture made with a needle. A local anesthetic is given to numb the insertion site. The catheter is then threaded through the major blood vessels and into the chambers of the heart and/or into the coronary arteries. The procedure is done in the hospital and takes 40 to 60 minutes.
Various small instruments can be advanced through the tube to the tip of the catheter. They include instruments to measure the pressure of blood in each heart chamber and in blood vessels connected to the heart, to view or take ultrasound images of the interior of blood vessels, to take blood samples from different parts of the heart, or to remove a tissue sample from inside the heart for examination under a microscope (biopsy). Common procedures done through the catheter include the following:
Coronary angiography: A catheter is used to inject a radiopaque contrast agent Labeling with a radionuclide In radionuclide scanning, radionuclides are used to produce images. A radionuclide is a radioactive form of an element, which means it is an unstable atom that becomes more stable by releasing... read more into the blood vessels that feed the heart (coronary arteries) so that they can be seen on x-rays.
Ventriculography: A catheter is used to inject a radiopaque contrast agent into one or more heart chambers so that they can be seen on x-rays.
Percutaneous coronary intervention (PCI): A catheter with a balloon attached to the tip is threaded into a narrowed coronary artery and the balloon is inflated to open the narrowed area. Doctors typically use the catheter to insert a wire mesh tube (a stent) into the artery to hold it open.
Valvuloplasty: A catheter is used to widen a narrowed heart valve opening.
Valve replacement: A catheter is used to replace a valve in the heart without removing the old valve or doing surgery.
Ventriculography is a type of angiography in which x-rays are taken as a radiopaque contrast agent is injected into the left or right ventricle of the heart through a catheter. It is done during cardiac catheterization. With this procedure, doctors can see the motion of the left or right ventricle and can thus evaluate the pumping ability of the heart. Based on the heart's pumping ability, doctors can calculate the ejection fraction (the percentage of blood pumped out by the left ventricle with each heartbeat). Evaluation of the heart's pumping helps determine how much of the heart has been damaged.
If an artery is used for catheter insertion, the puncture site must be steadily compressed for 10 to 20 minutes after all the instruments are removed. Compression prevents bleeding and bruise formation. However, bleeding occasionally occurs at the puncture site, leaving a large bruise that can persist for weeks but that almost always goes away on its own.
Because inserting a catheter into the heart may cause abnormal heart rhythms Overview of Abnormal Heart Rhythms Abnormal heart rhythms (arrhythmias) are sequences of heartbeats that are irregular, too fast, too slow, or conducted via an abnormal electrical pathway through the heart. Heart disorders are... read more , the heart is monitored with electrocardiography Electrocardiography Electrocardiography (ECG) is a quick, simple, painless procedure in which the heart’s electrical impulses are amplified and recorded. This record, the electrocardiogram (also known as an ECG)... read more (ECG). Usually, doctors can correct an abnormal rhythm by moving the catheter to another position. If this maneuver does not help, the catheter is removed. Very rarely, the heart wall is damaged or punctured when a catheter is inserted, and immediate surgical repair may be required.
Cardiac catheterization may be done on the right or left side of the heart.
Catheterization of the right side of the heart is done to obtain information about the heart chambers on the right side (right atrium and right ventricle) and the tricuspid valve (located between these two chambers) and evaluate the amount of blood the heart is pumping. The right atrium receives oxygen-depleted blood from the veins of the body, and the right ventricle pumps the blood into the lungs, where blood takes up oxygen and drops off carbon dioxide. In this procedure, the catheter is inserted into a vein, usually in the neck, arm, or the groin. Pulmonary artery catheterization Pulmonary Artery Catheterization The pulmonary artery is the artery that carries blood from the right side of the heart into the lungs. In pulmonary artery catheterization, a catheter is passed through the right atrium and... read more , in which a balloon at the catheter's tip is passed through the right atrium and ventricle and lodged in the pulmonary artery (which connects the right ventricle to the lungs), is sometimes done during catheterization of the right side of the heart during certain major operations and in intensive care units. Right-side catheterization is used to detect and quantify heart function and abnormal connections between the right and left sides of the heart. Doctors also use right-side catheterization when evaluating people for heart transplantation Heart Transplantation Heart transplantation is the removal of a healthy heart from a recently deceased person and then its transfer into the body of a person who has a severe heart disorder that can no longer be... read more or placing a mechanical device to help pump blood or for diagnosing and treating pulmonary hypertension Pulmonary Hypertension Pulmonary hypertension is a condition in which blood pressure in the arteries of the lungs (the pulmonary arteries) is abnormally high. Many disorders can cause pulmonary hypertension. People... read more or heart failure Heart Failure (HF) Heart failure is a disorder in which the heart is unable to keep up with the demands of the body, leading to reduced blood flow, back-up (congestion) of blood in the veins and lungs, and/or... read more .
Catheterization of the left side of the heart is done to obtain information about the heart chambers on the left side (left atrium and left ventricle), the mitral valve (located between the left atrium and left ventricle), and the aortic valve (located between the left ventricle and the aorta). The left atrium receives oxygen-rich blood from the lungs, and the left ventricle pumps that blood to the body. This procedure is usually combined with coronary angiography to obtain information about the coronary arteries.
For catheterization of the left side of the heart, the catheter is inserted into an artery, usually in an arm or the groin, and passed from that artery into the aorta, the large artery that carries blood from the heart.
In angiography Angiography In angiography, x-rays are used to produce detailed images of blood vessels. It is sometimes called conventional angiography to distinguish it from computed tomography (CT) angiography and magnetic... read more , a radiopaque contrast agent Radiographic Contrast Agents During imaging tests, contrast agents may be used to distinguish one tissue or structure from its surroundings or to provide greater detail. Contrast agents include Radiopaque contrast agents... read more , which is a liquid that can be seen on x-rays, is injected into a blood vessel and x-rays are taken to produce detailed images of the blood vessel. Coronary angiography provides information about the coronary arteries, which supply the heart with oxygen-rich blood. Coronary angiography is done during cardiac catheterization of the left side of the heart because the coronary arteries branch off the aorta just after it leaves the left side of the heart (see Blood Supply of the Heart Blood Supply of the Heart The heart and blood vessels constitute the cardiovascular (circulatory) system. The heart pumps the blood to the lungs so it can pick up oxygen and then pumps oxygen-rich blood to the body.... read more ). The two procedures are almost always done at the same time.
After injecting a local anesthetic, a doctor inserts a thin catheter into an artery through an incision in an arm or the neck or groin. The catheter is threaded toward the heart, then into the coronary arteries. During insertion, the doctor uses fluoroscopy (a continuous x-ray procedure) to observe the progress of the catheter as it is threaded into place.
After the catheter tip is in place, a radiopaque contrast agent is injected through the catheter into the coronary arteries, and the outline of the arteries appears on a video screen and is recorded.
Doctors use these images to detect blockages ( coronary artery disease Overview of Coronary Artery Disease (CAD) Coronary artery disease is a condition in which the blood supply to the heart muscle is partially or completely blocked. The heart muscle needs a constant supply of oxygen-rich blood. The coronary... read more ) or spasms of the coronary arteries. Images can help determine whether angioplasty Percutaneous Coronary Intervention Coronary artery disease is a condition in which the blood supply to the heart muscle is partially or completely blocked. The heart muscle needs a constant supply of oxygen-rich blood. The coronary... read more (opening the blockage with a small balloon inserted through the catheters) and stent placement (small, expandable hollow mesh tubes to keep the coronary artery open) is needed or whether coronary artery bypass surgery Coronary Artery Bypass Grafting Coronary artery disease is a condition in which the blood supply to the heart muscle is partially or completely blocked. The heart muscle needs a constant supply of oxygen-rich blood. The coronary... read more should be done to get blood past the area of blockage.
Miniature ultrasound transducers on the end of coronary artery catheters can produce images of coronary vessel walls and show blood flow. This technique (intravascular ultrasound or IVUS) is being increasingly used at the same time as coronary angiography. Miniature pressure sensors on the tip of the catheter can determine how much the pressure changes before and after a narrowing in a coronary artery. This technique (called fractional flow reserve or FFR) is used to determine the severity of the blood vessel narrowing.
Coronary angiography is seldom uncomfortable and usually takes 30 to 50 minutes. Unless the person is very ill, the person can go home a short time after the procedure. If a stent is placed, the person is usually kept overnight in the hospital.
When the radiopaque contrast agent is injected into the aorta or heart chambers, the person has a temporary feeling of warmth throughout the body as the contrast agent spreads through the bloodstream. The heart rate may increase, and blood pressure may fall slightly. Rarely, the contrast agent causes the heart to slow briefly or even stop. The person may be asked to cough vigorously during the procedure to help correct such problems, which are rarely serious. Rarely, mild complications, such as nausea, vomiting, and coughing, occur.
Serious complications, such as shock, seizures, kidney problems, and sudden cessation of the heart's pumping ( cardiac arrest Cardiac Arrest and CPR Cardiac arrest is when the heart stops pumping blood and oxygen to the brain and other organs and tissues. Sometimes a person can be revived after cardiac arrest, particularly if treatment is... read more ), are very rare. Side effects of radiopaque contrast agents Side effects of radiopaque contrast agents During imaging tests, contrast agents may be used to distinguish one tissue or structure from its surroundings or to provide greater detail. Contrast agents include Radiopaque contrast agents... read more include allergic reactions and kidney damage. Allergic reactions to the contrast agent range from skin rashes to a rare life-threatening reaction called anaphylaxis Anaphylactic Reactions Anaphylactic reactions are sudden, widespread, potentially severe and life-threatening allergic reactions. Anaphylactic reactions often begin with a feeling of uneasiness, followed by tingling... read more . The team doing the procedure is prepared to treat the complications of coronary angiography immediately. Kidney damage almost always goes away on its own. However, doctors are cautious about doing angiography in people who already have impaired kidney function.
Risk of complications is higher in older people, although it is still low. Coronary angiography is essential when angioplasty or coronary artery bypass surgery Percutaneous Coronary Intervention Coronary artery disease is a condition in which the blood supply to the heart muscle is partially or completely blocked. The heart muscle needs a constant supply of oxygen-rich blood. The coronary... read more is being considered.
